FAF2270K Check Valve With Counterweight

FEATURES

When flow begins in the direction defined on the system, the disc rotates the flow section around its axis, allowing the flow to pass through.
When subjected to flow in the opposite direction, it stops the flow.
Fixed disc within the body located on the flow axis.
Sealing is provided by a metal seating surface. A rubber-coated disc is available.
(Optional)
All external surfaces are primed and painted for corrosion resistance.
Can be manufactured with a counterweight for precise flow control. (FAF2270K optional)
Can be installed in vertical (vertical only) or horizontal (valve upright) applications.
Designed with a focus on easy access for maintenance. By removing a few bolts,
the valve assembly—including the hinge and disc—
can be removed from the body for maintenance.
Zero body leakage prevents media loss and complies with
environmental regulations.
Installation must be carried out with attention to the flow direction on the product.
TEMPERATURE

Y -10°C / +120°C (16 bar)
